• 2D Floor Plan
• 2D Elevation Design
• Structural Design

• Basement height : Upto 4 feet from Ground Level Car parking 3 feet
• Steel: Indrola TMT | JSW | TATA
• Aggregates: 20mm & 40mm
• Bricks: 9 inch for Exterior Wall & 9 inch for Interior Wall.
• Cement: Ramco | Chettinad | Ultratech
• M Sand: Brickwork
• P Sand & River Sand : Plastering
• RCC Design Mix: M20
• Ceiling Height: clear 11 Feet

• Ceramic Wall Tiles 2 Feet Above Kitchen Slab Upto 80Rs Per Sq ft
• Main Sink Faucet Upto Rs 5000 & Parryware | Jaquar
• Kitchen Sink: multi-function waterfall stainless steel smart kitchen sink worth of Rs.20,000
• Kitchen Granite Slab: 20 mm Thick Upto 250 Rs per Sq ft

• Wall Tiles For 11 Feet Upto 60-70Rs Per Sq ft
• Sanitary Ware & CP Fitting Upto Rs 65,000.
• CPVC/PVC: Finolex
• Bathroom Accessories: EWC, Health Faucet, Wash Basin with cabinet.
• All bathroom fittings are white color in Parryware brand/Jaquar brand
• PVC Flush Doors

Plumbing Points

• Bathroom – 1 wash basin with tap, 1 shower with wall mixer for hot & cold water, 1 floor mount western closet with health faucet.
• Dining – 1 wash basin with tap
• Kitchen – Single stainless steel sink with 1 tap.
• Service – 1 tap point & water outlet point for washing machine
• Solar water heater provision for all rooms.

• Main Door:  Teak Door With Teak Wood Frame of 5 Inch by 3 Inch, 38mm Thickness
• Internal Door: Flush Door(KAN-B) With Laminates Along With Teak Wood Frame of 4 Inch by 3 Inch
• Windows: Teak wood window window with Mosquito net.

Door sizes:

• Main Door – 5.5′(Width) X 7′(Height)
• Rooms – 3′(Width) X 7′(Height)
• Bathroom & Balcony – 2.5′(Width) X 7′(Height)
• Window size – 6′(Width) X 4′(Height), 4′(Width) X 4′(Height) (2 window per room)

• Interior:
  • 1 coat of asian white cement
  • 2 coat of Asian putty
  • 1 coat of primer and 2 coats of Asian brand royal emulsion paint for the walls (light colours)
  • 1 coat of primer and 2 coats of ACE emulsion paint for the ceiling
• Exterior:
  • 1 coat of asian white cement
  • 1 coat of Asian brand primer
  • 2 coats of Apcolite premium emulsion (light colours)

• Living & Dining Flooring: Tiles Upto 60-80 Rs Per Sq ft
• Room & Kitchen Flooring: Tiles Upto 60-80 Rs Per Sq ft
• Balcony & Open Area Flooring: Tiles Upto 60-80 Rs Per Sq ft
• Staircase Flooring: Anti-skid Tiles Upto 100 Rs Per Sq ft
• Parking Tiles: Anti-skid Tiles Upto 60 Rs Per Sq ft

• Wires – Finolex
• Switches – GM Cuba | Anchor Roma

Electrical Points

• Bedroom – 1 switch box with switches for 1 fan, 2 lights and 1 five amps socket with switch near door and another switch box with same set of switches near bed for two-way control.

  1 AC point, 1 fan point and 2 lights point

• Bathroom- 1 switch box with 1 switch for light and 1 switch for heater near the door & 15 amps socket for heater. 1 switch box with 1 five amps socket for hair dryer near the mirror
• Hall- 1 switch box near the door for 2 fans, 2 lights & 1 five amps socket and another switch box with same set of switches near sofa. 1 switch box with 1 five amps sockets and switches along with cable point for TV connection
• Dining-1 switch box with switches for 1 fan & 1 light
• Pooja- 1 switch box with switch for 1 light
• Kitchen- 1 switch box with switch for 2 lights, 1 exhaust fan. 1 switch box with 15 amps socket & switch for refrigerator. 1 switch box with one 15 amps socket & switch for mixie/ oven.
• Service-1 switch for light, 1 switch box with 15 amps socket & switch for washing machine

• Parapet wall upto 3 feet highand width 9 inches Thick
  (included if headroom is built)

Lofts & Shelves:

• 1 Loft in each bedroom, kitchen & pooja room on the shorter side of the wall
• 1 Shelf in kitchen & pooja room of maximum width 5 feet

• Additional foundation height
• Soil testing
• Structural designing
• 3D elevation designing
• Rainwater harvesting
• Outer area development (setback)
